Mechanical Specifications
- Body: Die-cast aluminum
- IP: IP66
- IK: IK09
- Color: RAL 9002 - RAL 7040 (Other custom colors available)
- Mounting: Top / Side
Optical Specifications
- Light Source: Lumileds SMD
- Color Temperature: 3000K, 4000K, Amber color
- Color Stability: >70 or >80
- Luminous Efficiency: 150 lm/W
- ULOR: 0%
- Optical Type: PMMA / PC
- Diffuser: 5mm tempered glass
- Photobiological Risk Group: RG0
Electrical Specifications
- Power Supply Voltage: 220-240V AC / 90-305V
- Frequency: 50/60Hz
- Class : I/II
- System Lifetime: 100,000 hrs at Ta 25°C (L90B10)
- Power Factor: >0.95
- Operating Temperature: -30°C to +50°C
- Standards: CE, CB, ENEC, ISO, LM79, TM21
Options
- DALI: Yes
- 1-10V: Yes
- 5-level Dimming: Yes
- NTC: Yes
- SPD: 10kV-10kA
- Socket: Zhaga / NEMA
